BX-5U series model:
●BX-5UT/5U0/5U1/5U2/5U3/5U4
Application:
●Specially used inWidely used in large area LED display
●Upload program by U disk,easy to install,free wiring
●Best choice for distributed cluster display system and high cost cabling areas
Feature:
●The single-USB interface LED display controller, no serial, operation more easy
●Powerful capacity in reading all kinds of USB disks
●3.5V- 6.5V wide voltage range, -40°C~80°C wide work temperature
●Flexible and rich display control, High performance price ratio, support firmware update by USB disk
●Parameters setting/Scan configuration/Program update can be completed conveniently by USB disk
●Correction time/Brightness adjustment/Timer for switch can be completed conveniently by USB disk
Technical parameters:
|
●Product model |
BX-5UT |
|
●Product status |
The latest 5th generation products,put into market on March 28,2012. |
|
●Control area |
Single color 16K 1024*16 512*32
Double color 8K 512*16 256*32 |
|
●Memory Storage
●Screen types |
2MByte
All kinds of single and double colors LED screen at the height of 36 pixels |
|
●Software function |
Screens cluster management/multi-program/multi-areas display/multi-languages |
|
●Program quantity |
Support 32programs,8areas for each program |
|
●Area type |
Picture and text/single line text/animation/lunar calendar/digital clock/
analogue clock/timer/temperature/temperature & humidity |
|
●Program type |
Normal/global/real-time/shared/self-adapted program |
|
●Frame mode |
Most advanced colorful / magic graphics frame/Area frame |
|
●Background |
Support text/image/colorful and active background |
|
●Time mode |
Analogue clock/digital clock/timing and counting-down timer (support multi-groups) |
|
●Communication mode |
USB download |
|
●Interface |
1groups T8 and 2 groups of T12 |
|
●Sensors supported |
Supported temperature and humidity sensors |
|
●Remote control |
Remote control program/lock screen/brightness adjustment/power on/off /screen test |
|
●Bright regulation |
16 grades brightness, manual and auto-timing adjustment/remote control |
|
●Power on/off mode |
Auto-timing powered on/off /remote control |
|
●Voltage |
5V(3.5V~6.5V ) |
|
●Maximum power |
≤2W |
|
●Temperature |
-40°C~80°C |
|
●Secondary development |
Provide the DLL and corresponding demos |
|
●Adapter |
Without |
|
●Application fields |
Specially used in car and small area strip LED display |
|
●Software |
LedshowTW2013 |
|
●User manual |
LEDshowTW 2013 software user manual |
Notes: Because of the update, the actual functions and parameters may have some differences with the one on the website.
