Name£º Linsn Receiving Card 901
Detailed£º

LED Display Receiving Card Linsn 901

RV901H/921H/931H is upgraded from the 8th generation system RV801. Compared with RV801, RV901 has all functions
 of RV801 and can replace RV801, besides, RV901 is added the following functionality:
¡ñ1. support 12-bit HDMI colors input (required the 9th generation sending card)
¡ñ2. using18-bit signal processor, maximum support 18-bit (260,000) gray (each of red, green and blue)
¡ñ3. Single card maximum supports 1024X256 pixels, and 1024 grades single pixel chromaticity correction
¡ñ4. Supports single-card color space conversion
¡ñ5. Support configuration file readback
¡ñ6. Support program replication
¡ñ7. Supports hot backup with dual receiver cards for demanding performances screen
¡ñ8. Supports pixel fault detection (requires a dedicated chip support)
¡ñ9. Support network cable BER test
¡ñ10. Support flat cable fault detection
¡ñ11. Support the cabinet-door monitoring (open/close)
¡ñ12. Two lines fan-speed monitoring
¡ñ13. Three lines Voltage monitoring: one for the system, two for cabinet power
¡ñ14. Temperature monitoring
¡ñ15. Humidity monitoring (humidity sensor sold separately)
¡ñ16. Smoke monitoring (smoke module sold separately)
¡ñ17. In line with EU standards CE-EMC
