Name: P7.62
Detailed:

P7.62 Indoor Single Color Led Module

Item

Unit

Parameter

Pixel Pitch

mm

7.62

Resolution of Module

dots

64×32

Module Size

mm

484×242

Module Weight

kg

1.10kg

Pixel Configuration

                    1R

Chip Brand of LEDs

                     Silan/Epistar

Pixel Density

dots/sqm

44,321

Brightness (White Balance)

nits(cd/sq.m)

400

Red Wavelength

nm

620-625

Scan Mode

                           1/16 Scan

Viewing Distance

M

2--15

 Best View Distance

M

5--8

Viewing Angle-Horizontal

deg.

120

Viewing Angle-Vertical

deg.

120

Max. Power Consumption

W/sq.m

200

Avg. Power  Consumption

W/sq.m

130

Working Voltage

                          40A 5V

Power Supply

                          AC 110/220V

Refresh Rate

Hz/S

300

Frame Rate

Hz/S

 60

Gray Scale

                           256 grade

Display Function

                       Text

Input Signal

                  RS232/485, USB,Ethernet

Luminance Degradation

Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25°C.

Defective Dot Rate

                            <0.0001

Life Span

hours

100,000

MTBF

hours

>5,000

Storage Temperature

°C

 -35 -- +80

Working Temperature

°C

         -20 -- +60

Working Humidity

                              10-90%RH

Control System

Asynchronization or Synchronization

Quality Certificate

ETL,CE,RoHS,TUV,FCC class A,ISO9001:2008

Warrenty

2 Years

Working Environment

Indoor

Note: The above parameter is just for your reference. It can be changed according to customers' requirements
