P10 Outdoor Led Display Module |
|
|
|
Pixel Information |
Pixel Pitch |
10mm |
|
Pixel Density |
10000 Pixels/m2 |
|
Pixel Configuration |
1R1G1B |
|
LEDs Brand |
Red: Silan/Epistar / Cree |
|
Green: Silan/Epistar / Cree |
|
Blue: Silan/Epistar / Cree |
|
LEDs Wavelength |
Red: 615 nm - 625 nm |
|
Green: 520 nm - 535 nm |
|
Blue: 465 nm - 475 nm |
|
LED Module |
Module Size |
160 mm (Width) × 160 mm(Height) = 0.0256/m² |
|
|
Module Resolution |
16 pixels(Width) × 16 pixels(Height) = 256 pixels |
|
|
LED Cabinet |
Cabinet Size |
960 mm(Width) × 960mm(Height) = 0.92/m² |
|
|
Cabinet Resolution |
96 Pixels(Width) × 96 Pixels(Height) = 9216 Pixels |
|
|
Total QYT Module Per Cabinet |
6 Modules(Width) × 6 Modules(Height) = 36 Module |
|
|
Cabinet Weight |
50 kgs |
|
Cabinet Material |
Steel or aluminum |
|
Power |
Input Voltage |
100-240V AC, 50/60Hz |
|
Max Power Consumption |
750 Watt/ m² |
|
Avg. Power Consumption |
380 Watt/ m² |
|
Viewing |
White Balance |
X= 0.33 Y= 0.33 5600°K(Adjustable up to 9000°K) |
|
Brightness |
≥6500cd/m2 |
|
Brightness Uniformity |
Luminance Discrepancy < 5% |
|
Colors |
16777216 |
|
Grey Scale(Level) |
4096 |
|
Slot Between Neighboring Modules |
< 1 mm |
|
Best Viewing Angle |
Horizontal:120°/ Vertical:60° |
|
Viewing Distance |
10 - 150 meters |
|
|
Ambint Conditions |
Temperature Range |
Storage:-40 °c to +85°c.; Working:-20°c to +60°c |
|
Operating Humidity |
10%90%RH |
|
Ingression Protection Grade |
Front Side: IP65 (Resist spraying of water gun directly); |
|
Back Side: IP54 (Resist Rain) |
|
Processing |
Scanning Mode |
1/4 Scan |
|
Refresh Frequency |
180HZ-600HZ, Adjustable |
|
Signal Input |
DVI, Composite Video for Live Video |
|
Supported Networking |
Through LAN/WAN, RS 232/RS485 |
|
|
|
Controller |
Linsn, Xixun, DB-star, etc. |
|
Other |
Life Span |
50,000 - 100,000 Hours |
|
Software |
Nova Star |
